Introduction

In order to enable the waveplate suitable for high damage threshold (more than 1GW/cm2) application Banner Union provides a single plate of true zero order waveplate with mounts upon request. The thickness of this waveplate The handling of the waveplate is so difficult due to the thin thickness we can provide mounts upon request.



Standard Specifications




Items

Specifications

Material

Crystal Quartz

Wavelength Range

1000-2100 nm

Dimension Tolerance

+0.0/-0.2 mm

Thickness Tolerance

± 0.2 mm

Clear Aperture

> 80%

Parallelism

< 5 arc Seconds

Wavefront Distortion

<λ/8 @632.8 nm

Retardation Tolerance

<λ/500

Surface Quality

scratch and dig 20-10

Coating

R<0.2%





Part NO.

Diameter (mm)

TYPE

WPS0101

10.0

Quarter Waveplate

WPS0102

12.7

Quarter Waveplate

WPS0103

15.0

Quarter Waveplate

WPS1101

10.0

Half Waveplate

WPS1102

12.7

Half Waveplate

WPS1103

15.0

Half Waveplate
