Introduction

Titanium doped Sapphire (Ti:Sapphire) is the most widely used laser crystal for widely tunable and ultrashort pulsed lasers with high gain and power outputs. we possesses the advanced growth method of Temperature Gradient Technique (TGT) and it supplies large-sized (Dia.30x30mm) Ti:Sapphire crystal in high quality free of light scatter with the dislocation density less than 102cm-2. The TGT grown sapphire crystal is characterized by the (0001) oriented growth high doping level (α490 = 4.0cm-1) high gain and laser damage threshold.



Standard Specifications




Items

Specification

Orientation

Optical axis C normal to rod axis

Ti2O3 concentration

0.06 - 0.26 at. m%

Figure Of Merit(FOM):

100~250 (>250 available on special requests)

α490

1.0~4.0cm-1

Diameter

2~30mm or specified

Path Length

2~30mm or specified

End configurations

Flat/Flat or Brewster/Brewster ends

Flatness

<l/10 @ 633 nm

Parallelism

<10 arc sec

Surface Quality

Scratch and dig 40-20

Wavefront distortion

l/4 per 25 mm
