Introduction |
 |
 |
Yb:YAG is one of the most promising laser-active materials and more suitable for diode-pumping than the traditional Nd-doped systems. diode lasers a longer upper-laser level lifetime three to four times lower thermal loading per unit pump power. Yb:YAG crystal at 1030nm is a good substitute for a Nd:YAG crystal at 1064nm and its second harmonic at 515nm may replace Arion laser(with a large volume) which emit at 514nm. |
|
| |
 |
 |
|
|
Standard
Specifications |
|
|
|
Items |
Specifications |
|
Dopant concentration |
Yb: 5~25 at% |
|
Wavefront Distortion |
≤ 0.125λ/inch |
|
Extinction Ratio |
≥28 dB |
|
Rod Sizes |
Diameter:2~20mm,Length:5~150mm
Upon request of customer |
|
Dimensional Tolerances |
Diameter:+0.00"/-0.002"mm,
Length: ± 0.02" |
|
Parallelism |
≤10" |
|
Perpendicularity |
≤5′ |
|
Flatness |
λ/10 |
|
Surface Quality |
10-5 |
|
AR Coating Reflectivity |
≤0.2 %( @1064nm |
|
Single pass loss |
<3×103cm-1 | |
|
| |
|
Advantage
Very low fractional heating less than 11%
Very high slope efficiency
Broad absorption bands about 8nm@940nm
No excited-state absorption or up-conversion
Conveniently pumped by reliable InGaAs diodes at 940nm(or 970nm)
High thermal conductivity and large mechanical strength
High optical quality
Long life time and good thermal conductivity
|
|
