Introduction

The magneto-optical crystal TGG is an optimum material for Faraday devices (Rotator and Isolator) in the range from 400nm-1100nm excluding 470-500nm.The Faraday rotator consists of a TGG rod contained inside a special designed magnet. The rotation sense of the polarization of a light beam passing through the rotator only depends on the direction of the magnetic field and not on the direction of propagation of the light beam. The optical isolator is a Faraday rotator set between two suitably aligned polarizer which allow a light beam to pass through in one direction only. TGG has a combination of excellent properties such as large Verdet constant low light loss high thermal conductance and high light damage threshold which makes it a unique material for Faraday devices particularly suitable for YAG lasers and Ti: sapphire tunable lasers ring lasers and seed injected lasers.




Standard Specifications




Items

Specification

Orientation

[111] within 5 degrees

Wave Front Distortion

< 1/8 Lambda @ 633 nm

Extinction Ratio

> 30dB

Diameter Tolerance

+0.00mm/-0.05mm

Dimension Tolerance

¡À0.2mm

Flatness

¡Ü¦Ë/ 10@ 633nm

Surface Quality

Scratch and Dig 10-5

Parallelism

< 30 arc second
